Description |
Honda Part Number |
Unit Price |
|
1: COVER R CRANK CAS |
11331-MJ8-000 |
Not Available |
|
2: GASKET,R.COVER |
11394-KBV-000 |
|
|
2: (11394-KBV-000) GASKET,R.COVER |
11394-KE8-000 |
Superceded |
|
2: (11394-KBV-000) GASKET,R COVER |
11394-KE8-306 |
Superceded |
|
3: CAP,OIL FILLER |
15611-MB0-000 |
|
|
4: GAUGE,OIL LEVEL |
15650-MJ8-010 |
|
|
5: CLAMP,PULSER CORD |
30301-MB0-000 |
|
|
6: CLAMP, SWITCH WIRE |
35211-MJ8-000 |
Not Available |
|
7: CLAMP,SWITCH CORD |
35211-443-760 |
|
|
8: (90084-471-000) CAP,ACG |
90084-428-000 |
Superceded |
|
8: CAP,A.C.GENERATOR |
90084-471-000 |
|
|
9: O-RING,13.8X2.5 |
91303-MG7-003 |
|
|
9: (91303-MG7-003) O-RING,13.8X2.5 |
91303-377-000 |
Superceded |
|
9: (91303-MG7-003) O-RING,13.8X2.5 |
91303-426-000 |
Superceded |
|
10: O-RING,21.5X3.2 |
91307-425-003 |
|
|
11: O-RING,8.4X2.4 |
91316-MJ8-003 |
|
|
12: DOWEL,PIN,8X14 |
94301-08140 |
|
|
13: (96001-060-3207) BOLT,FLG,SH. 6X32 |
96000-06032-07 |
Superceded |
|
13: BOLT,FLANGE,6X32 |
96001-06032-07 |
|
|
14: (96001-060-4007) BOLT,FLANGE,6X40 |
96000-06040-07 |
Superceded |
|
14: BOLT,FLANGE,6X40 |
96001-06040-07 |
|
|
