Description |
Honda Part Number |
Unit Price |
|
3: CYLINDER COMP,FR. |
12100-MF5-000 |
|
|
4: (12191-MM9-850) GASKET,CYLINDER |
12191-MF5-000 |
Superceded |
|
4: (12191-MM9-850) GASKET,CYLINDER |
12191-MM9-306 |
Superceded |
|
4: GASKET,CYLINDER |
12191-MM9-850 |
|
|
5: HEAD SET,CYLND |
12200-MF5-305 |
|
|
5: (12200-MF5-305) HEAD,FR.CYLINDER |
12210-MF5-000 |
Superceded |
|
6: PIPE A,OIL PATH |
12230-MF5-000 |
|
|
7: GUIDE,IN,VALVE |
12231-MF5-305 |
|
|
8: (12241-MF5-315) GUIDE,EX.VALVE |
12241-MF5-305 |
Superceded |
|
8: GUIDE,EX.VALVE |
12241-MF5-315 |
|
|
9: (12251-MF5-405) GSKT,CYLIN.HEAD |
12251-MF5-000 |
Superceded |
|
9: GASKET.CYLN.HEAD |
12251-MF5-405 |
|
|
10: INSULATOR,CARB. |
16211-MF5-000 |
|
|
11: BAND,INSULATOR |
16219-ME9-000 |
|
|
13: BOLT,FLANG,SOKET |
90009-MF5-000 |
|
|
14: BOLT,OIL CONTROL |
90045-MF5-000 |
|
|
15: BOLT CYLIN 8X180 |
90081-MF5-003 |
|
|
16: BOLT SPEC 7X26.5 |
90085-MF5-000 |
|
|
17: NUT 10MM |
90204-634-000 |
|
|
17: NUT, HEX. (10MM) |
94030-10000-07 |
Not Available |
|
17: NUT, FLANG, 10MM |
94050-10000 |
|
|
18: WASH,SEALING,7MM |
90441-MC0-000 |
|
|
19: WASHER 5MM |
90452-323-000 |
|
|
20: WASHER,OIL BOLT |
90545-300-000 |
|
|
21: BOLT,STUD,6X35 |
92900-06035-0E |
|
|
22: SCREW CROSS 5X8 |
93500-05008-0G |
|
|
23: SCREW,PAN,5X25 |
93500-05025-0G |
|
|
24: NUT,FLANGE,8MM |
94050-08080 |
|
|
25: DOWEL,PIN,14X20 |
94301-14200 |
|
|
26: (96001-060-7000) BOLT,FLANGE,6X70 |
96000-06070-00 |
Superceded |
|
26: BOLT,FLANGE,6X70 |
96001-06070-00 |
|
|
27: SPARK PLUG(NGK) |
98069-57916 |
|
|
27: SPARK PLUG (ND) |
98069-57926 |
|
|
27: SPARK PLUG (NGK) |
98069-58916 |
|
|
27: SPARK PLUG (ND) |
98069-58926 |
|
|
27: SPARK PLUG (NGK) |
98069-59916 |
|
|
27: SPARK PLUG (ND) |
98069-59926 |
|
|
